756 BSewing unit for runstitching straight and slanted pocket openings with fully automatic feeding device
• Unique programmable material adjustment for easy setting of different material thicknesses by the operator – pocket materials of different thick-ness can be processed one after the other with-out mechanical adjustments • New piping cutting technology: Simultaneous, timesaving cutting of the piping ends using step-per motor technology – perfect incisions even in sensitive materials • Jacket outer pockets: Time saving approx. 50% due to automatic cutting of piping ends and si-multaneous attaching of two pocket bags • Perfect folder system: improved material pas-sage – simple, fast and low-cost exchange of folder and sole inserts • Improved loading devices for easy loading of the piping strips on the piping tray • Quick change of needle distance faster, more convenient and cost-effective Field of application • Blazer-, Jacket outer pockets • Trousers-, lining pockets Performance features • Approx. 2,000 – 2,400 pockets without flaps / 480` • Approx. 1,600 – 2,000 pockets with flaps / 480` • Max. sewing speed 3,000 stitches/min • Needle distances: 8.0 – 20.0 mm |
